3 in 1 Dehumidifying Dryer

3 in 1 Dehumidifying Dryer

Model
HCF-15 HCF-25 HCF-50 HCF-75 HCF-100 HCF-150 HCF-200 HCF-300 HCF-400
MOQ
1 SET
Payment
L/C, T/T, Western Union
Port of Loading
Guangzhou / Shenzhen
Brand
HENGJU
Material
Stainless Steel
Certification
CE, TUV, UL
Availability
OEM/ODM
Delivery Time
7-15 working days
Supply Ability
200SETS /Month
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:

APPLICATION


The  dehumidifying dryer combine a dehumidifying and drying system in a single unit. They have better drying effect for  plastic materials such as PA,PC,PBT ,PET,PMMA, PLA, TPU,TPE, etc.

Hengju-High Efficiency Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-3
All in One Dryer

For home appliances production.

Hengju-High Efficiency Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-4
All in One Dryer

For PET preform production.

Hengju-High Efficiency Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-5
Dehumidifying Dryer

For PET preform production.

...
Plastic Dehumidifying Dryer

For plastic container production.

Hengju-Custom 3-in-1 Dehumidifying Dryer Manufacturer Manufacturer-4
Desiccant Dryer for IMM

For injection molding production.

Hengju-Custom 3-in-1 Dehumidifying Dryer Manufacturer Manufacturer-5
Desiccant Dryer

For auto parts production.

Hengju-Custom 3-in-1 Dehumidifying Dryer Manufacturer Manufacturer-6
All in One Dryer

For one injection molding machine.

Hengju-Custom 3-in-1 Dehumidifying Dryer Manufacturer Manufacturer-7
All in One Dryer

For two injection molding machines.




DETAILS



Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving

Part 1
Dew-point Instrument
Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-1

Part 2
Honeycomb Wheel
Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-2

Part 3
Moister Tester


VIDEO



PRODUCT INFORMATION


FEATURES

  • ❶     The 3 in 1 compact designed for dehumidifying dryer assures that the drying process is operating in the entire sealed system, avoiding to humidify again the raw materials contacts to the air after being dried, achieving as good drying results.

  • ❷     Mircocomputer P.I.D control system, with protective functions of over-heat protection, motor overloaded, motor reverse protection, delayed cooling downtime.

  • ❸     Alternative for touch-screen liquid crystal display, are available to display operational conditions, trouble shooting and maintenance instructions.

  • ❹      Low dew point reach -40℃ to ensure materials drying completely by dried air.

  • ❺     Downwards blowing design to prevent heat loss and increase drying efficiency.

  • ❻     Double insulating hopper prevents heat loss and maintains regular temperature.

  • ❼     With advanced technology,provides safely,reliable,space-saving and high performance.


SPECIFICATIONS



Model

HCF-15

HCF-25

HCF-50

HCF-75

HCF-100

HCF-150

HCF-200

HCF-300

HCF-400

Drye hopper

Capacity (L)

15

25

50

75

100

150

200

300

400

Heat protection

material

Fiberglass+Staninless Steel

Dry air dew-point

—40℃

Temperature (℃)

80-160

Blower power (kw)

0.75

0.75

1.1

1.5

2.2

3

5.5

7.5

7.5

Regeneration lower (kw)

0.25

0.25

0.25

0.55

0.55

0.75

0.75

2.2

2.2

Drying heater (kw)

3.9

5.4

5.4

7.2

12

15

18

21

21

Regeneration heater (kw)

3.9

3.9

3.9

5.4

5.4

7.2

7.2

10

10

Pipe sizes

Drying (mn)

51

51

51

63

63

76

76

100

100

Cooling (lnch)

3/4"

Regeneration (mn)

38

38

38

51

51

51

51

63

63

Conveying blower (kw)

1.1

1.1

1.1

1.5

1.5

1.5

2.2

3.7

3.7

Conveying
distance (m)

Stage 1

10

Stage 2

10

Hose size (Inch)

1.5

2

2

Sensor hopper capacity (L)

6

6

6

6

6

6

6

10

10

Vacuum hopper capacity (L)

6

6

6

6

6

6

6

10

10

Dimension (LxWxH) (cm)

100×87×180

100×87×180

100×87×180

123×95×239

165×130×225

150×130×280

178×130×286

214×138×316

225×138×349

Approx.Net Weight (KG)

310

340

360

420

550

600

750

830

900



PRODUCTION



Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-7

R & D Research

Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-8

Laser Cutting

Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-9

Bending


Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-10

Welding

Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-11

Assembling

Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-12

Testing



PACKAGE & DELIVERY



Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-13
Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-14
Hengju-Plastic Hopper Dryer, 3 In 1 Dehumidifying Dryer Energy Saving-15
