Model
HY-90D HY-100D HY-110D HY-120D
MOQ
1PCS
Payment
L/C, T/T, Western Union
Port of Loading
Guangzhou / Shenzhen
Brand
HENGJU
Material
Stainless Steel
Certification
CE, TUV, UL
Availability
OEM/ODM
Delivery Time
3-15 Days
Supply Ability
500PCS/Month
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Enterprise Strength
  • Hengju Machinery Equipment runs the business in good faith and puts customers in the first. We are dedicated to providing quality services for customers.
Company Advantages
1. The design style of Hengju is in line with international standards.
2. This product is anti-shrinkage. Mechanical shrinking process is carried out to force the fabric to shrink width and/or lengthwise, so as to creates a fabric in which any residual tendency to shrink is minimal.
3. This product has good color fastness. The fabric retains its original color after a long time of use and multiple washes.
4. Dongguan Hengju Machinery Equipment Co., Ltd's advantages are well known by our customers.

PRODUCT INFORMATION



FEATURES

  • ❶     Liner slider rail and alloy aluminum extrusion applied for arm, low noise, long use life.

  • ❷     900/1000/1100/1200for single stage type.

  • ❸     The telescopic version uses an unique, nylon belt transmission mechanism inside the vertical arm assembly, shorten the time and reducing the height of the whole machine

  • ❹     Servo driven on traverse to carry out the function of multiple spot place positioning precision up to ±0.1mm .



  • SPECIFICATIONS



    ModelHY-90DHY-100DHY-110DHY-120D
    Power capacity (kva)111
    Recommended IMM (Ton)200-350350-450400-550350-600
    Recommended IMM (mm)1300(1540)1540(1800)1540(1800)2000(2200)
    Traverse drivenStandard Y : AC Servo Motor        Option M : Inverter motor
    Crosswise stroke (mm)P:300P:300P:300P:400
    R:150R:150R:150R:200
    Vertical stroke (mm)900100011001200
    Max loading (kg)5101010
    Dry take out time (sec)2.42.52.83
    Dry cycle time (sec)121414.518
    Air consumption (NI/cycle)29374075
    PowerAC 220V ±10V 50/60HZ
    Power capacity0.2
    Working pressure5 kgf/cm² 0.49Mpa
    Max. allowed pressure8 kgf/cm² 0.8Mpa
    Drive modeY inverter motor/AC servomotor X,Z pneumatic cylinder
    Swivel90° Fixed Pneumatic
    Control systemSGCX-AM3 / SGCX-AY3
    Net weight (KG)220-260335-370355-380450-530



    DETAILS



    Hengju-1
    Part 1
    Liner slider rail and alloy aluminum extrusion applied for arm, low noise, long use life
    Hengju-2
    Part 2
    Control panel



    APPLICATION



    Hengju-3
    Hengju-4



    VIDEO





    PRODUCTION



    Hengju-5

    R & D Research

    Hengju-6

    Laser Cutting

    Hengju-7

    Bending


    Hengju-8

    Welding

    Hengju-9

    Assembling

    Hengju-10

    Testing



    PACKAGE & DELIVERY



    ;

    Hengju-11
    Hengju-12
    Hengju-13



Company Features
1. Dongguan Hengju Machinery Equipment Co., Ltd is an international brand that focuses on innovative research and development.
2. Quality speaks louder than number in Dongguan Hengju Machinery Equipment Co., Ltd.
3. Our goal is to, to the greatest extent, bring together technology, people, products, and data, so that we can create solutions that help our customers succeed. We will embrace the principles of environmental sustainability across the board. We are making some tremendous efforts in going green by slashing our energy usage and supporting green energy projects.
