❶ The modulized components can be disassembled for easy cleaning.
❷ The adopted PLC panel shows reliable performance and easy maintenance.
❸ The adopted functions such as advanced algorithm of controlling, autonomous optimization, automatic calibration and anti-vibration, can ensure the highest accuracy.
❹ The standard models can process four dosing. (Six-dosing modules can be customized)
❺ Touch screen operation is achieved with multiple languages option and diagrams with colors
❻ Up to 100recipes can be stored for later use
❼ The gravimetric blender is adopted with Multilevel password protection and keep alarm records
❽ Standard USB2.0 interface is easy for saving recipe data into flash disk, and hence fulfill the quality control management
❾ With sound and flash alarm, operators can be informed shortly and evidently for reparation
❿ All raw material contact parts are made of stainless steel, which can prevent the materials being polluted
The gravimetric blender can be directly mounted on the injection machine or optional stand frame near the injection machine
|Qty of Group number||4||4||4||4||4||4||4||4||4||4|
|main material mixing range（%）||5~100||5~100||5~100||5~100||5~100||5~100||5~100||5~100||5~100||5~100|
|additive mixing range（%）||0.5~10||0.5~10||0.5~10||0.5~10||0.5~10||0.5~10||0.5~10||0.5~10||0.5~10||0.5~10|
|main hopper volume（L）||18||25||32||45||70||100||130||160||180||230|
|additive hopper volume（L）||18||25||32||45||70||100||130||160||180||230|
|mixing barrel volume（L）||6||6||20||20||40||40||80||80||100||180|
|compressed air （kgf/cm2）||6~8|
|max. noise level（dB）||<75|
◪ Hopper low material level alarm switch.
◪ Automatic loading control module.
◪ Pneumatic slide gate(adapted for injection machine mounting models).
◪ Floor stand frame, pneumatic slide gate, storage tank and suction box are adapted for floor mounting models.
◪ Ethernet interface,MODBUS,PROFIBUS communication modules, can fulfill the remote monitoring. They can also transfer data with extrusion machines and injection machines .
