Water Cooled Chiller

Water Cooled Chiller

Model
HJW-1 HJW-2 HJW-3 HJW-4 HJW-5 HJW-8 HJW-10 HJW-12 HJW-15 HJW-20 HJW-25 HJW-30 HJW-40 HJW-50
MOQ
1PCS
Payment
L/C, T/T, Western Union
Port of Loading
Guangzhou / Shenzhen
Brand
HENGJU
Material
Stainless Steel
Certification
CE, TUV, UL
Availability
OEM/ODM
Delivery Time
3-15 Days
Supply Ability
500PCS/Month
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:

APPLICATION



Hengju-Best Water Chiller Water Cooled Chiller Central Chillers Manufacture-2
Central Dosing & Mixing System

For PET preform production.

Hengju-Best Water Chiller Water Cooled Chiller Central Chillers Manufacture-3
Central Dosing & Mixing System

For PET preform production.

Hengju-Best Water Chiller Water Cooled Chiller Central Chillers Manufacture-2
Central Dosing & Mixing System

For PET preform production.

Hengju-Best Water Chiller Water Cooled Chiller Central Chillers Manufacture-3
Central Dosing & Mixing System

For PET preform production.

Hengju-Best Water Chiller Water Cooled Chiller Central Chillers Manufacture-2
Central Dosing & Mixing System

For PET preform production.

Hengju-Best Water Chiller Water Cooled Chiller Central Chillers Manufacture-3
Central Dosing & Mixing System

For PET preform production.

Hengju-Best Water Chiller Water Cooled Chiller Central Chillers Manufacture-2
Central Dosing & Mixing System

For PET preform production.

Hengju-Best Water Chiller Water Cooled Chiller Central Chillers Manufacture-3
Central Dosing & Mixing System

For PET preform production.




DETAILS



Hengju-Best Water Chiller Water Cooled Chiller Central Chillers Manufacture
Part 1
Liquid crystal display showing temperatures of outlet and inlet chill water-provides visualized and direct setting.
Hengju-Best Water Chiller Water Cooled Chiller Central Chillers Manufacture-1
Part 2
After Industrial Design, The Shape Is Beautiful.



VIDEO




PRODUCT INFORMATION



FEATURES

  • ❶     Famous brand new compressors,high efficient shell condensers and evaporators -- excellent cooling,quiet with low electric consumption.

  • ❷     P.I.D. Microprocessor control--easy to operate,accurately maintains temperature range from 3℃ to 50℃

  • ❸     Special open type reservoir tank with stainless steel -- easy to clean and maintain.

  • ❹     Well design and reasonable Pipelines--ensures power supply and saves energy.

  • ❺     Current-overload protector,high-and-low pressure switches,electronic time delayer,fault display system--Safe and durable.

  • ❻     Liquid crystal display showing temperatures of outlet and inlet chill water-provides visualized and direct setting.

  • ❼     Single,double or quadruple compressors combination available--economic and effcient.

  • ❽     Industrially designed--elegant and economic with friendly human-machine connections.



  • SPECIFICATIONS



    ModelUnitHJW-1HJW-2HJW-3HJW-4HJW-5HJW-8HJW-10HJW-12HJW-15HJW-20HJW-25HJW-30HJW-40HJW-50
    Cooling CapacityKW2.775.287.9112.915.2223.830.534.345616992122136
    Kcal/h238245416803110941309120468262302949838700524605934079120104920117476
    CompressorInput PowerKW0.891.772.84.55.23x24.5x2104.5x39x210x29x39x49.4x4
    Rated PowerHP123564x25x26x25x310x212.5x210x310x412.5x4
    Power1PH-220V/50HZ3PH-380V/50HZ( 200V/220V/415V 50HZ/60HZ )1PH-220V/51HZ3PH-380V/50HZ( 200V/220V/415V 50HZ/61HZ )
    EvaporatorType
    Water Tank With Coil(Shell And Tube)
    Pipe Diameterinch6'6'1''1''1''2''22''2''2.5''2.5''3''3''3''
    RefrigerantType
    R22












    QuantityKG1.61.8222.54557.51111121818
    Water CondenserType














    Pipe Diameterinch

    1''1''1''2''2''2''2''2.5''2.5''3''3''3''
    Cooling Water Flowm3/h0.4760.9081.362.222.63.954.425.037.18.8410.0613.617.7521.9
    Air CondenserType
    Finned Copper Tybe + Low Noise Outer Rotor Fan






    Fan PowerW85x185x1135x1135x2135x2420x2420x2550x2750x2550x3750x3800x3800x3800x4
    Water Tank CapacityLiter2020506060110110110200350350420420420
    PumpPowerKW0.370.370.370.370.750.750.750.751.51.52.22.244
    HP0.50.50.50.51111223355
    Distancem2323232335131313151516161616
    Flow RateL/min100100100100110200200200360360650650700700
    Safety Protection
    High And Low Pressure Protection, Overload Protection,Over Temperature Protection,Phase Sequence Protection,etc.
    Dimensions(L*W*H)Water Cooledmm

    935* 500*883935*500*883935*500*8831270*650*14131270*650*14131270*650*14131270*750*14131880*880*16501880*880*16501880*880*16502150*1080*19502150*1080*1950
    Air Cooledmm800*490*898795*566*1058960*630*10731280*630*11181280*630*11181550*830*15431550*830*15431550*830*15431850*1000*16402150*1000*18202400*1150*17402600*1150*19402150*2000*18202400*2250*1840
